Product Information
SPECIFICATION | |||||
PANEL | |||||
Display Type | DLED | ||||
Aspect Ratio | 16:9 | ||||
Resolution | 1920*1080 | ||||
Brightness | 230cd/m2 | ||||
Contrast | 3000:1 | ||||
Viewing Angle | 178°* 178° | ||||
Display Colors | 16.7M | ||||
Response Time | 8ms | ||||
AUDIO | |||||
ATV | BG,DK,I | ||||
DTV | MPEG-1 layer 1/2, DD, DD+ | ||||
Stereo Sound | NICAM | ||||
Maximum Audio Output | 2×8W (speaker 8Ω10W） | ||||
Equalizers | YES | ||||
Effects | YES | ||||
VIDEO | |||||
ATV | PAL SECAM | ||||
DTV | DVB-T/T2/C/S/S2 | ||||
INPUTS/CONNECTIONS | |||||
RJ45 | 1 | ||||
OPTICAL | 1 | ||||
HDMI1.4 | 3 | ||||
AV IN | 1 | ||||
*TV1(S2) | 1 | ||||
TV2(ATV/DVB-T/C/T2) | 1 | ||||
USB2.0 | 2 | ||||
CI | 1 | ||||
POWER | |||||
Power consumption(Operation) | 90W | ||||
Power consumption(Standby) | ≦0.5W | ||||
Power Requirement | AC 100-240 50/60Hz | ||||
CERTIFICATIONS | |||||
CB/CE-LVD | TBD | ||||
CE-EMC | TBD | ||||
ERP | TBD | ||||
RoHS | TBD | ||||
REACH | TBD | ||||
ACCESSORIES | |||||
Remote Controller(English) | YES | ||||
Wall-mount Bracket | OPTIONAL | ||||
Remote Batteries | YES | ||||
User Manual | YES | ||||
Stand | YES | ||||
CONVENIENCE | |||||
Progressive Scan | YES | ||||
HD Ready | YES | ||||
HDMI Resolution | 480i/p,576i/p, 720p, 1080i/p | ||||
Color Temperature Adjustment | YES | ||||
SOLUTION | |||||
EL.MT9256-FG75（MT9256chip DVB) | |||||
system configuration | |||||
WIFI | IEEE 802.11 b/g/n | ||||
OS | Android 13 | ||||
DDR | 1G | ||||
eMMC FLASH | 8G | ||||
CPU | Arm Cortex-A55*4 1.5GHz | ||||
GPU | Mali-G31 MP2 | ||||
RJ45 NETWORK | 10/100M auto-identification and DHCP | ||||
OTHER | |||||
HDMI | ARC | ||||
HDCP KEY | 1.4 /2.2 | ||||
Dolby | AC-3/DD+ | ||||
ACCESSORY | |||||
User's Manual | YES | ||||
Remote Control | YES | ||||
Specifications
RANGS 40'' FRAMELESS SMART VOICE CONTROL ANDROID LED TV: SPECIFICATION PANEL Display Type DLED Aspect Ratio 16:9 Resolution 1920*1080 Brightness 230cd/m2 Contrast 3000:1 Viewing Angle 178°* 178° Display Colors 16.7M Response Time 8ms AUDIO ATV BG,DK,I DTV MPEG-1 layer 1/2, DD, DD+ Stereo Sound NICAM Maximum Audio Output 2×8W (speaker 8Ω10W） Equalizers YES Effects YES VIDEO ATV PAL SECAM DTV DVB-T/T2/C/S/S2 INPUTS/CONNECTIONS RJ45 1 OPTICAL 1 HDMI1.4 3 AV IN 1 *TV1(S2) 1 TV2(ATV/DVB-T/C/T2) 1 USB2.0 2 CI 1 POWER Power consumption(Operation) 90W Power consumption(Standby) ≦0.5W Power Requirement AC 100-240 50/60Hz CERTIFICATIONS CB/CE-LVD TBD CE-EMC TBD ERP TBD RoHS TBD REACH TBD ACCESSORIES Remote Controller(English) YES Wall-mount Bracket OPTIONAL Remote Batteries YES User Manual YES Stand YES CONVENIENCE Progressive Scan YES HD Ready YES HDMI Resolution 480i/p,576i/p, 720p, 1080i/p Color Temperature Adjustment YES SOLUTION EL.MT9256-FG75（MT9256chip DVB) system configuration WIFI IEEE 802.11 b/g/n OS Android 13 DDR 1G eMMC FLASH 8G CPU Arm Cortex-A55*4 1.5GHz GPU Mali-G31 MP2 RJ45 NETWORK 10/100M auto-identification and DHCP OTHER HDMI ARC HDCP KEY 1.4 /2.2 Dolby AC-3/DD+ ACCESSORY User's Manual YES Remote Control YES
Service Warranty 5 Years; Parts & Panel Warranty 2 Years.
