Product Information
PARAMETERS | UNITS | KSV-12BDINV GOLDEN | |
About Model | Type of Ac | Details | Split |
Details | Inverter | ||
Details | Cooling only | ||
Power supply | Rated Voltage & phase | Volts | 230V, Single |
Rated frequency | Hz | 50 | |
Cooling | Withstanding Voltage & Frequency | V-Hz | 130V-280V-50HZ |
Withstanding Operating conditions : ODU | °C | 20-46 | |
Cooling Area | m2 | 90-120 sq feet | |
Capacity(Rated) | Watt | 3517 | |
Power(Rated) | Watt | 1120 | |
EER(Rated) | W/W | 3.14 | |
Cooling Input Current | A | 4.86 | |
Max. Input Power | Watt | 1380 | |
Max. Input Current | A | 7 | |
General | Indoor side air flow (Rated) | m3/h | 570 |
Indoor side noise level (Rated) | dB(A) | 43.5 | |
Dimensions (L*W*H) | mm | 832 x 292 x 210 | |
Packing (L*W*H) | mm | 910 x 365 x 285 | |
Weight : Net & Gross | Kg | 10.7±0.5 & 12.85±0.5 | |
Motor | Motor Type : Single Phase Induction | Details | Wolong, YYW25-4-5201L |
Motors Mechanical output Wattage | Watt | 25 W | |
Capacitor | uF | 1.5 uF | |
Indoor Fan speed (Rated) | r/min | 1200 | |
Thermal protector | Yes/ No | Yes | |
Best AC Price List in Bangladesh (BD) for March, 2024
| Product Model | Price in BD |
|---|---|
| Rangs RAC-14SH 01 Ton Split Type AC (RAC-14SH) | 40900 |
| Rangs RAC-19SH 1.5 Ton Split Type AC (RAC-19SH) | 50900 |
| Kelvinator 1 Ton Split Type AC (KSV-12NVBD) | 46900 |
Questions About This Product (0)
Specifications
: PARAMETERS UNITS KSV-12BDINV GOLDEN About Model Type of Ac Details Split Details Inverter Details Cooling only Power supply Rated Voltage & phase Volts 230V, Single Rated frequency Hz 50 Cooling Withstanding Voltage & Frequency V-Hz 130V-280V-50HZ Withstanding Operating conditions : ODU °C 20-46 Cooling Area m2 90-120 sq feet Capacity(Rated) Watt 3517 Power(Rated) Watt 1120 EER(Rated) W/W 3.14 Cooling Input Current A 4.86 Max. Input Power Watt 1380 Max. Input Current A 7 General Indoor side air flow (Rated) m3/h 570 Indoor side noise level (Rated) dB(A) 43.5 Dimensions (L*W*H) mm 832 x 292 x 210 Packing (L*W*H) mm 910 x 365 x 285 Weight : Net & Gross Kg 10.7±0.5 & 12.85±0.5 Motor Motor Type : Single Phase Induction Details Wolong, YYW25-4-5201L Motors Mechanical output Wattage Watt 25 W Capacitor uF 1.5 uF Indoor Fan speed (Rated) r/min 1200 Thermal protector Yes/ No Yes
10 Years Compressor & 02 Years Parts & Service Warranty
