Product Information
Model Name | RSDC-12RTSI | |||||
Type | Coolling only | |||||
Control type | Remote | |||||
Power supply | Ph-V-Hz | 1Ph-220-240V~50Hz | ||||
Voltage Range | V | 198~242 | ||||
Cooling | Capacity | Btu/h | 12000(2730~12500) | |||
Capacity | W | 3200(800~3665) | ||||
Rated power Input | W | 1053(250~1450) | ||||
Rated current | A | 4.9(1.2~7.5) | ||||
EER | W/W | 3.04 | ||||
Max power Input | W | 1450 | ||||
Max current | A | 7.5 | ||||
Indoor coil | a.Number of rows | 2 | ||||
b.Tube pitch(a)x row pitch(b) | mm | 21×12.7 | ||||
c.Fin spacing | mm | 1.5 | ||||
e.Tube outside dia.and type | mm | Φ7,innergroove tube | ||||
f.Coil length x height x width | mm | / | ||||
g.Number of circuits | 1 in 2 out | |||||
Outdoor coil | a.Number of rows | 1 | ||||
b.Tube pitch(a)x row pitch(b) | mm | 19.5×11.6 | ||||
c.Fin spacing | mm | 1.2 | ||||
e.Tube outside dia.and type | mm | Φ5,innergroove tube | ||||
f.Coil length x height x width | mm | / | ||||
g.Number of circuits | 1 in 1 out | |||||
Indoor unit | Dimension(W*D*H) | mm | 776×250×202 | |||
Packing (W*D*H) | mm | 850×320×275 | ||||
Net/Gross weight | Kg | 8/10 | ||||
Outdoor unit | Dimension(W*D*H) | mm | 787×290×498 | |||
Packing (W*D*H) | mm | 818×325×520 | ||||
Net/Gross weight | Kg | 22/26 | ||||
Pressure | High(DP) | MPa | 4.5 | |||
Low(SP) | MPa | 1.9 | ||||
Refrigerant | R410A/0.53kg | |||||
Ambient temperature | ℃ | -15~50 | ||||
Suitable area | m2 | 15~23 | ||||
Connecting Wiring |
| 4×1.0mm²×5.8m | ||||
Power supply cord | AWG16 | |||||
| 310 | |||||
Best AC Price List in Bangladesh (BD) for March, 2024
| Product Model | Price in BD |
|---|---|
| Rangs RAC-14SH 01 Ton Split Type AC (RAC-14SH) | 40900 |
| Rangs RAC-19SH 1.5 Ton Split Type AC (RAC-19SH) | 50900 |
| Kelvinator 1 Ton Split Type AC (KSV-12NVBD) | 46900 |
Specifications
RANGS 01 TON SMART-WI-FI INVERTER SPLIT TYPE AC: Model Name RSDC-12RTSI Type Coolling only Control type Remote Power supply Ph-V-Hz 1Ph-220-240V~50Hz Voltage Range V 198~242 Cooling Capacity Btu/h 12000(2730~12500) Capacity W 3200(800~3665) Rated power Input W 1053(250~1450) Rated current A 4.9(1.2~7.5) EER W/W 3.04 Max power Input W 1450 Max current A 7.5 Indoor coil a.Number of rows 2 b.Tube pitch(a)x row pitch(b) mm 21×12.7 c.Fin spacing mm 1.5 e.Tube outside dia.and type mm Φ7,innergroove tube f.Coil length x height x width mm / g.Number of circuits 1 in 2 out Outdoor coil a.Number of rows 1 b.Tube pitch(a)x row pitch(b) mm 19.5×11.6 c.Fin spacing mm 1.2 e.Tube outside dia.and type mm Φ5,innergroove tube f.Coil length x height x width mm / g.Number of circuits 1 in 1 out Indoor unit Dimension(W*D*H) mm 776×250×202 Packing (W*D*H) mm 850×320×275 Net/Gross weight Kg 8/10 Outdoor unit Dimension(W*D*H) mm 787×290×498 Packing (W*D*H) mm 818×325×520 Net/Gross weight Kg 22/26 Pressure High(DP) MPa 4.5 Low(SP) MPa 1.9 Refrigerant R410A/0.53kg Ambient temperature ℃ -15~50 Suitable area m2 15~23 Connecting Wiring Size x Core number 4×1.0mm²×5.8m Power supply cord AWG16 Qty 40'HQ 310 Best AC Price List in Bangladesh (BD) for March, 2024 Product Model Price in BD Rangs RAC-14SH 01 Ton Split Type AC (RAC-14SH) 40900 Rangs RAC-19SH 1.5 Ton Split Type AC (RAC-19SH) 50900 Kelvinator 1 Ton Split Type AC (KSV-12NVBD) 46900
10 Years’ Compressor & 02 Years’s Parts & Service.
